2010
Ford F-250SD
1
/
2
2010 Ford F-250SD Lariat
Available
Visit our Store
- Ford of Madisonville
-
581 Interstate 45 North
Madisonville, TX 77864
- Sales: 936-349-9752
- Service: 936-349-9834
- Parts: 936-349-9728
Vehicle Information
VIN:
1FTSX2BY1AEA11869
Stock #:
26090B
Model Code:
X2B
-
Body Style 4D Extended Cab -
Mileage 171,526
-
Engine 6.8L V10 30V MPFI SOHC -
Transmission 5-Speed Automatic -
Fuel Type Gasoline
Dealer Comments
Recent Arrival!
Triton 6.8L V10 EFI SOHC 30V, 4WD, ABS brakes, Alloy wheels, AM/FM radio: SIRIUS, Compass, Front dual zone A/C, Heated door mirrors, Heated front seats, Illuminated entry, Low tire pressure warning, Remote keyless entry, SIRIUS Satellite Radio.
Awards:
* 2010 KBB.com Brand Image Awards
Triton 6.8L V10 EFI SOHC 30V, 4WD, ABS brakes, Alloy wheels, AM/FM radio: SIRIUS, Compass, Front dual zone A/C, Heated door mirrors, Heated front seats, Illuminated entry, Low tire pressure warning, Remote keyless entry, SIRIUS Satellite Radio.
Awards:
* 2010 KBB.com Brand Image Awards
Eligible Benefits
All Features
- Manual transfer case & hubs
- 4-wheel drive
- 157-amp HD alternator
- Trailer tow pkg-inc: 7-wire harness w/relays, 7/4 pin combination connector
- 12.5K trailer hitch receiver-inc: 2" hitch
- 6-3/4' pickup box-inc: (4) tie-down hooks, partitionable & stackable storage
- (2) front tow hooks
- Mono-beam front axle w/coil spring suspension
- HD gas shock absorbers
- Front stabilizer bar
- Pwr steering w/steering damper
- Pwr 4-wheel disc brakes w/vacuum boost
- 2-ton mechanical jack
- (5) LT245/75R17E all-season BSW tires
- 17" argent painted steel wheels w/painted hub covers & center ornaments
- Full-size spare tire w/lock & carrier
- Black painted steel front bumper w/grained mold-in-color top cover
- Black painted rear bumper
- Front fender vents
- Box-rail & tailgate top-edge moldings
- Black painted grille
- Sealed beam halogen headlamps
- Pickup box/cargo lights
- Manual telescoping trailer tow mirrors w/manual glass
- Solar tinted glass
- Flip-out rear quarter windows
- Interval windshield wipers
- Dual rear access doors
- Front/rear license plate brackets
- Black door handles
- Removable locking tailgate w/black handle & Tailgate Assist
- AM/FM stereo-inc: clock, (2) speakers
- Air conditioning
- HD vinyl bench seat w/recline & integrated armrest -inc: cupholders in armrest (w/213 ESOF Transfer Case, REQ: 445 or 447 Manual Trans)
- Vinyl fold-up rear bench seat
- Black vinyl full-floor covering
- Carpet delete
- Color-keyed scuff plates
- SecuriLock anti-theft ignition
- (4) air registers w/positive shut-off
- Auxiliary pwr point
- Dash-top tray
- Glove box
- Instrument panel mounted storage bin & trash bag hook
- Color-keyed molded door trim panel-inc: hard armrest, grab handle, reflector
- Color-keyed cloth headliner
- Front passenger-side roof ride handle
- Driver & front passenger grab handles
- Dual color-keyed cloth sunvisors-inc: driver-side pocket, passenger-side mirror insert
- Front door operated dome lamp w/time delay off & IP switch
- Front map lamps
- Dual color-keyed coat hooks
- 4-wheel anti-lock braking system (ABS)
- Driver & front passenger airbags w/passenger-side deactivation switch
- SOS post crash alert system
- Color-keyed safety belts w/front seat outboard height adjustable D-rings
- BeltMinder seatbelt-not-buckled chime & flashing warning light
- Child seat tethers on all rear passenger seats
- Tire pressure monitoring system
- 4 Speakers
- AM/FM radio: SIRIUS
- CD player
- Premium Electronic AM/FM Stereo w/Single CD
- SIRIUS Satellite Radio
- Air Conditioning
- Automatic temperature control
- Front dual zone A/C
- Power driver seat
- Power steering
- Power windows
- Remote keyless entry
- Steering wheel mounted audio controls
- 4-Wheel Disc Brakes
- ABS brakes
- Dual front impact airbags
- Front anti-roll bar
- Low tire pressure warning
- Passenger cancellable airbag
- Rear Parking Sensors
- Delay-off headlights
- Front fog lights
- Fully automatic headlights
- Panic alarm
- Security system
- Speed control
- Bumpers: chrome
- Heated door mirrors
- Power door mirrors
- Rear step bumper
- Turn signal indicator mirrors
- Auto-dimming Rear-View mirror
- Compass
- Driver door bin
- Driver vanity mirror
- Front reading lights
- Illuminated entry
- Leather steering wheel
- Outside temperature display
- Overhead console
- Passenger vanity mirror
- Tachometer
- Tilt steering wheel
- Trip computer
- Front Bucket Seats
- Front Center Armrest
- Heated front seats
- Leather Seating Surfaces Luxury Capt's Chairs w/Heat
- Power passenger seat
- Split folding rear seat
- Passenger door bin
- 18" Premium Forged Aluminum Wheels
- Alloy wheels
- Variably intermittent wipers
- 3.73 Axle Ratio
- Cold Cranking Amps @ 0° F (Primary): 650
- Maximum Alternator Capacity (amps): HD 157
- Maximum Alternator Watts: 1950
- Total Cooling System Capacity (qts): 27.5
- Total Cooling System Capacity (qts): 26.4
- Gross Axle Wt Rating - Front (lbs): 4800
- Gross Axle Wt Rating - Front (lbs): 4400
- Gross Axle Wt Rating - Rear (lbs): 6100
- Curb Weight - Front (lbs): 3789
- Curb Weight - Front (lbs): 3654
- Curb Weight - Rear (lbs): 2611
- Curb Weight - Rear (lbs): 2613
- Gross Vehicle Weight Rating Cap (lbs): 9400
- Gross Vehicle Weight Rating Cap (lbs): 9200
- Gross Combined Wt Rating (lbs): 21000
- Gross Combined Wt Rating (lbs): 16000
- Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
- Dead Weight Hitch - Max Tongue Wt. (lbs): 500
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 12500
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 9500
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 1875
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 1425
- Fifth Wheel Hitch - Max Trailer Wt. (lbs): 14400
- Fifth Wheel Hitch - Max Trailer Wt. (lbs): 9500
- Fifth Wheel Hitch - Max Tongue Wt. (lbs): 3600
- Fifth Wheel Hitch - Max Tongue Wt. (lbs): 2375
- Suspension Type - Front: Coil
- Suspension Type - Rear: 2-Stage Leaf
- Spring Capacity - Front (lbs): 4800
- Spring Capacity - Front (lbs): 4400
- Spring Capacity - Rear (lbs): 6100
- Axle Type - Front: Dana Super 60 Monobeam
- Axle Type - Rear: Visteon Full-Floating
- Axle Capacity - Front (lbs): 6000
- Axle Capacity - Rear (lbs): 6200
- Axle Ratio (:1) - Front: 4.10
- Axle Ratio (:1) - Rear: 4.10
- Shock Absorber Diameter - Front (mm): 35
- Shock Absorber Diameter - Rear (mm): 35
- Stabilizer Bar Diameter - Front (in): 1.10
- Brake Type: Pwr
- Brake ABS System: 4-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness (in): 13.66 x 0.58
- Rear Brake Rotor Diam x Thickness (in): 13.39 x 0.47
- Front Tire Order Code: TBK
- Rear Tire Order Code: TBK
- Spare Tire Order Code: TBK
- Front Tire Size: LT245/75R17E
- Rear Tire Size: LT245/75R17E
- Spare Tire Size: LT245/75R17E
- Front Tire Capacity (lbs): 3195
- Rear Tire Capacity (lbs): 3195
- Spare Tire Capacity (lbs): 3195
- Revolutions/Mile @ 45 mph - Front: 664
- Revolutions/Mile @ 45 mph - Rear: 664
- Revolutions/Mile @ 45 mph - Spare: 664
- Front Wheel Size (in): 17 x 7.5
- Rear Wheel Size (in): 17 x 7.5
- Spare Wheel Size (in): 17 x 7.5
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Spare Wheel Material: Steel
- Steering Type: Pwr
- Steering Ratio (:1), On Center: 17.0
- Steering Ratio (:1), At Lock: - TBD -
- Turning Diameter - Curb to Curb (ft): 47.5
- Turning Diameter - Wall to Wall (ft): 49.4
- Frame Type: Ladder-Type
- Fuel Tank Capacity, Approx (gal): 30.5
- Fuel Tank Location: Midship
- Wheelbase (in): 141.8
- Length, Overall w/o rear bumper (in): 231.8
- Width, Max w/o mirrors (in): 79.9
- Height, Overall (in): 79.4
- Overhang, Front (in): 37.6
- Overhang, Rear w/o bumper (in): 52.4
- Front Bumper to Back of Cab (in): 139.9
- Cab to Axle (in): 40.0
- Cab to End of Frame (in): 80.4
- Ground to Top of Load Floor (in): 34.5
- Ground to Top of Frame (in): - TBD -
- Frame Width, Rear (in): 37.6
- Ground Clearance, Front (in): - TBD -
- Ground Clearance, Rear (in): 7.0
- Cargo Box Length @ Floor (in): 81.8
- Cargo Box Width @ Top, Rear (in): 63.5
- Cargo Box Width @ Floor (in): 69.3
- Cargo Box Width @ Wheelhousings (in): 50.9
- Cargo Box (Area) Height (in): 20.1
- Tailgate Width (in): 60.6
- Cargo Volume (ft³): 64.4
- Passenger Capacity: 6
- Front Head Room (in): 41.4
- Front Leg Room (in): 41.0
- Front Shoulder Room (in): 68.0
- Front Hip Room (in): 67.6
- Second Head Room (in): 38.4
- Second Leg Room (in): 31.8
- Second Shoulder Room (in): 68.1
- Second Hip Room (in): 67.3
- Vehicle Name: Ford Super Duty F-250 SRW
- Body Style: Supercab 6-3/4'
- Body Code: 142" WB
- Tons/yr of CO2 Emissions @ 15K mi/year: - TBD -
